Dragon scale Armor Battery

The cell adopts innovative bottom explosion-proof valve design, and the system level adopts advanced "heat-electricity separation" design, and double-sided cooling design to enhance the heat exchange capacity; The structure combines high-strength steel + elastic bracket design, multiple designs to ensure safety performance.

  • c6fldesz.png

    76%

    Grouping rate

  • c6fldesz.png

    800km+

    LFP

  • c6fldesz.png

    900km+

    H-LMFP

  • c6fldesz.png

    1000km+

    NCM


Structural Advantages

  • 安全.svg

    Ultimate safety

    Innovative design of cells and battery packs to ensure safe application in all aspects

  • 续航.svg

    Ultimate driving range

    The ultimate use of space brings mileage breakthrough

  • 性能.svg

    Outstanding performance

    The upper and lower large water-cooling plates and the top cover of battery pack are integrated with the water-cooling plates, and a bottom water-cooling plate is added.

  • 成本.svg

    Ultimate cost

    The electrical connection area of the battery pack is reduced, resulting in reduced costs compared to the LCTP1.0 matrix battery pack

  • 效率.svg

    Strong compatibility

    Meet diversified demand of customers,compatibility with A00-C levels and to Extensible CTC/CTB

Innovative Technology

  • c6_img02.jpg

    Innovative cell structure

    Explosion-proof valve design at the bottom, shorten internal gas channels
    Targeted pressure relief in case of abnormal abuse

  • c6_img03.jpg

    Thermal - electrical separation design of battery pack

    The thermal runaway pressure relief zone and the electrical connection zone are independent of each other
    Internal high-voltage arcing is reduced

  • c6_img06.png

    Elimination of central exhaust channel

    Shrinkage of Y-direction thermal exhaust and thermal isolation space in battery pack

  • jg1.png

    High-strength steel + elastic bracket at the bottom of the battery pack

    Merging of the thermal runaway pressure relief channel with the bottom protection space

LCTP1.0

Dragon scale Armor Battery

download.png download.png

The architecture of dragon armor battery enhances the heat exchange capacity to ensure lower charging and heat release temperature.

  • c6fldesz.png

    +70%

    Heat exchange capacity

  • c6fldesz.png

    4C

    Fast charging capacity

LCTP1.0

Dragon scale Armor Battery

download.png download.png

Dragon armour battery structure, simplified structure to reduce processes and the weight service life

  • c6fldesz.png

    -20%

    Structural components

  • c6fldesz.png

    -10~20KG

    Whole package weight


A00-C level

Various chemical systems

Compatible with L300-L600 cells of various sizes

Three-in-one design

Extensible CTC/CTB

Battery pack cover, water cooling plate, vehicle floor , three- in -one
