Craftsmanship and Perseverance for the Basic Technology
Advanced staking process is adopted for SVOLT products and all series products have undergone penetration test to ensure safety.
Penetration test
-
Short Blade Cell
-
Energy Storage System
350Ah specialized cell for electric energy storage
Extremely safe, long-life energy storage short blade cells
325Ah specialized cell for electric energy storage
Extremely safe, long-life energy storage short blade cells
730Ah specialized cell for household energy storage
Extremely safe, long-life energy storage short blade cells
Energy density
>171 Wh/Kg
Efficiency
>94%
Ultimate safety
Staking technology
High cycle
8000
Energy density
>165 Wh/Kg
Efficiency
>94%
Ultimate safety
Staking technology
High cycle
9000
Energy density
>185 Wh/Kg
Efficiency
>94%
Ultimate safety
Staking technology
High cycle
8000
3340kWh Liquid-cooled ES Container
Based on the 222Ah Fly-stacking cell and a 1P liquid-cooled energy storage system, it offers extreme temperature control and is designed for GWh-level energy storage power stations.
5160kWh Liquid-cooled ES Container
Based on the 350Ah thermally compounded laminated battery cells, this industry-unique dual-layer liquid-cooled energy storage system offers exceptional temperature control, ensuring worry-free operation for GWh-level energy storage power stations.
C&I Energy Storage Cabinet
Based on the 222Ah thermally compounded laminated battery cells, the system adopts a modular design, making it compatible with photovoltaic, storage, diesel, and microgrid systems, and supports both grid-connected and off-grid operations.
Energy Storage All-in-One Unit
Based on the 350Ah lamination short-blade battery cells, the industry's first short-blade CTR energy storage system has been introduced, further advancing space efficiency, cost-effectiveness, and full-life-cycle performance.
High-Rate Application
Utilizes high-rate Fly-stacking laminated cells specifically designed for large-scale ESS applications
Products support 1P applications, used for peak shaving, grid-level frequency regulation, renewable energy integration, etc.
Ultimate Safety
Cells: "Lamination" process ensures intrinsic ultimate safety
System: Intelligent early warning + three-level fire protection, ensuring safety throughout the lifecycle
High Efficiency and Intelligence
1P Charge-Discharge characteristics reduce initial investment for station-level power plants
Compared to 0.5P systems, 1P systems can reduce initial capacity by 50%
Ultra-long Lifespan
Battery Cells endure over 8000 lifecycles under 1P conditions
Ultra-long Lifespan
Industry's first lamination short-blade battery cell, with over 10,000 cycles
Fully upgrade of thermal management system, dual-sided liquid cooling reduces temperature difference by 50%, increasing system lifespan by 10%
Ultimate Safety
Cells: "Short-blade + Lamination" process ensures intrinsic safety, passing extreme nail penetration tests
System: Intelligent early warning + three-level fire protection, ensuring safety throughout the lifecycle
High Efficiency and Intelligence
System energy efficiency is 1% higher than the industry average
Energy density per unit area is 3% higher than the industry average, with 2.8% higher usable energy
Multi-scenario Applications
Supports single-rack management, enhancing energy utilization and reducing inter-rack current circulation
The product supports peak shaving, grid-level frequency regulation, and renewable energy integration
Ultra-long Lifespan
The 222Ah laminated battery cells feature low internal resistance and high consistency, with a cycle life exceeding 8000 cycles, making them suitable for frequent charging and discharging needs in commercial and industrial applications.
Flexibility and Economy
Modular design supports capacity expansion as needed, and efficient DC-side integration reduces conversion losses, significantly lowering the cost per kilowatt-hour over the entire lifecycle.
Ultimate Safety
The battery cells are inherently resistant to high temperatures and thermal runaway, combined with liquid cooling technology and a multi-layer protection system, effectively mitigating the risk of thermal runaway.
Intelligent Maintenance
The BMS (Battery Management System) monitors cell status in real-time, with cloud-based intelligent diagnostics, improving maintenance efficiency by 50%.
Minimalist Design
Adopts CTR pack-less design, rack structural strength +30%, components reduced by 36%, significantly saving deployment space
Ultimate Safety
Cells: "Short blade + lamination" process achieves intrinsic ultimate safety and passes extreme nail penetration tests
System: Intelligent early warning ensures safety throughout the lifecycle
High Efficiency and Intelligence
Integrated unit directly connects on the DC side to reduce conversion losses, supports modular parallel expansion, and features built-in AI-BMS for real-time optimization of charge-discharge strategies, improving maintenance efficiency by 60%
Ultra-long Lifespan
Industry's first lamination short-blade energy battery cell, with over 10,000 cycles
Fully upgrade of the thermal management system, dual-sided liquid cooling reduces temperature difference by 50%, increasing system lifespan by 10%
Application Scenarios
-
Electricity scenario
Specialized products for large-capacity electric energy storage are linked with photovoltaic, thermal power, wind power, grid dispatch and other systems through energy management systems.
The big data platform and energy management system can quickly and accurately adjust energy storage charging and discharging strategies based on power generation and grid scheduling needs.
-
Commercial scenarios
High-quality commercial energy storage products can achieve real-time monitoring of remaining capacity and load size of power lines with the support of energy management systems, and can interact with energy units such as distributed photovoltaics and charging equipment.
The big data platform and energy management system can quickly and accurately adjust the energy storage charging and discharging strategies based on the different energy consumption conditions monitored.
-
Family scenario
Diversified home energy storage products that support DIY appearance and achieve self-sufficiency in household energy and effectively store renewable energy such as solar and wind energy.
In the event of a power outage or sudden malfunction in the power grid, household energy storage can be put into standby mode to ensure basic electricity consumption.
Energy replenishment can be achieved during peak electricity consumption to supplement insufficient power supply in the power grid and avoid grid overload and faults.
-
Electricity scenario
Smoothing fluctuations, improving forecasting accuracy, enhancing new energy generation capacity, conducting joint frequency regulation, participating in auxiliary services, achieving large-scale flexible peak-shaving, and improving power factor and other functions.
-
Commercial scenarios
Conducting peak load shifting to alleviate the energy burden during peak hours, providing emergency power supply, and coordinating with charging piles to alleviate capacity shortages, which can participate in auxiliary services.
-
Family scenario
Household energy supply, balancing grid load, emergency backup, optimizing electricity consumption and management, and reducing energy costs.
They are Using Products from SVOLT
-
100MWh Shared Energy Storage Project of Nyocor in Shishou
50MW/100MWh
Rated total installed capacity of energy storage system
This project is the first shared electrochemical energy storage power station of SVOLT, with a rated total installed capacity of 50MW/100MWh for the energy storage system.
Shared energy storage can reduce the investment cost of new energy projects, play a role in power regulation, and promote the matching of power supply and demand. Furthermore, it can also enhance the regulatory support capacity of the power grid system, and significantly increase the installed capacity and grid connection scale of renewable energy such as photovoltaic and wind power.
-
50MW Project of Integration of Agriculture, Photovoltaic Power Generation of CNNC in Tengzhou
5MW/10MWh
Project installation
The project was officially put into operation on December 30, 2020, with an installed capacity of 5MW/10MWh. It is one of the first batch of photovoltaic power station energy storage projects in Shandong, equipped with many functions such as peak load shifting, AGV/C dispatching, primary/secondary frequency regulation, etc. It can meet various requirements such as charging by abandoned light, demand side response, and grid side safety.
-
Guangdong User Side Stereoscopic Energy Storage Project
19MW/38MWh
Project volume
Site 1: Located on the reserve land outside the parking lot of Lens Technology Park in Dongguan City, the project has a volume of 19MW/38MWh. A three-dimensional energy structure is constructed in the project by utilizing the reserve land. The steel structure overhead method is adopted to achieve integrated application of light storage and charging, solving the problems of parking, charging, and peak load shifting in the park.
Site 2: Located in Dongguan Internet Industrial Park, the project has a volume of 500kWMh. It makes full use of the park space to solve the parking, charging, peak load shifting, power backup and other problems in the park through three-dimensional methods.
-
Dual Adjustment Cascade 1.5MW Energy Storage Project of Southern Power Grid
1.5MW/4.9MWh
Project installation
The project was officially put into operation on April 30, 2021, with an installed capacity of 1.5MW/4.9MWh. It is a demonstration project for the utilization of lithium iron phosphate cascade modules, with functions such as peak load shifting, AGVC dispatching, and regulation, to achieve demand side response and cascade energy utilization.
-
400MWh Energy Storage Project in Awat, Xinjiang
5.0176MWh
Single unit capacity
For the Grid-Connected 400000 KW Photovoltaic + Energy Storage Marketization Project of Guangdong Hydropower Group in Awat County, SVOLT provided a total of 80 prefabricated battery compartments, with a single unit capacity of 5.0176 MWh and a total capacity of 401.408 Wh. The energy storage system can achieve applications such as solar energy storage integration, energy transfer, primary frequency regulation, secondary frequency regulation, reactive power support, short-circuit capacity, black start, virtual inertia, damping, etc. in conjunction with photovoltaic power generation. Furthermore, the energy storage system can accept grid dispatching and participate in grid auxiliary services.
